Keeping today's records for tomorrow's tools.

Some of the tools that will read your records have yet to be written, and the systems you use today each keep what suits them, for as long as it suits them: build logs expire, the ticket goes with the tracker, the branch is squashed. Ranke keeps the material itself — every record as it arrived, with who filed it, when, and what it was built from. It stays structured and navigable in the meantime, so an agent can walk the archive, and a scoped export hands what a question needs to the analysis system of your choice.

What an archive keeps

An archive is a collection of records: letters, photographs, minutes, recordings. Each one was taken in, and the taking-in was itself recorded.

So every record carries two dates: when it entered the archive and its presumed date of origin. It carries who put it there. It carries what it is. None of this describes the world the record speaks about; it describes the record, and that is what makes the record usable as evidence rather than as information.

Nothing changes after entering the archive. A document that turns out to be wrong keeps its place; a later record says so, and both stay readable. Contradiction is part of what the archive holds, because which account is right is often decided long after both were filed.

Every record belongs to a body of material. Cataloguing, summaries and analyses are filed too, each saying what it drew on. A century of that work leaves a structure, and the structure is what makes anything findable.

Archives have done this since the nineteenth century.

Digital systems keep history: git every version of a file, an issue tracker every comment, a build system its logs. Each keeps its own, under its own policy: one squashes, one prunes after 90 days, one is append-only, and several cannot be exported at all. The history is scattered, and no system holds what runs across them.

What Ranke does with it

Ranke-Graph takes the archival form literally. Everything enters as a claim: a file, a commit, a scan result, a message. A claim holds the bytes as they were, the time it entered, who put it there, and edges to the claims it was built from. Nothing is overwritten or removed, and no claim can be written without saying what it rests on.

That constraint is where the order comes from. The structure is the citations themselves, so there is no catalogue to maintain, and following them always ends at something that entered from outside. Whatever an agent or a colleague answers from the archive, the path back to the original record is part of the answer.

Ranke-Graph is a format. The graph is the content, and any store that holds bytes under a key can hold it: a filesystem, S3, Postgres, Neo4j, or more than one at once. RankeDB serves it and decides who may read and write. Without RankeDB the archive is still a set of self-describing files.

Answering is a tool's job, and the archive gives it two ways in. A client traverses the graph in place: a prompted agent, a worker built on the SDKs, anything that can follow an edge to what a claim cites. Or an export hands a scoped cut to a system built for the question — this year's mail for one, a release's evidence for another. The archive stays behind both, so a system adopted next year, or one still to be written, starts from the whole record.

Choosing what goes into a cut is archive work in itself, and the graph carries enough structure to do it here. Every claim states what it rests on, so the archive can be searched and walked without a knowledge system on top: an agent gathers the records a question needs and says what it drew on. That selection can be filed as a claim of its own, and a later reading can then see how the cut was made.

Available now

Snapshot a git repository

Import a repository, the full history or a single commit. Each file becomes a claim of its own, linked to the commit, and the commit to the repository. The snapshot restores byte-identical to the original.

Ask when a vulnerable dependency first entered, and the answer names the commit, the author and the moment, with the bytes to check it against.

ranke-git
Next

More adapters, and a generic export

Email and chat threads, issue trackers, CI build logs, and security scan reports each need an adapter: a small program that reads a source and turns it into claims. The export runs the other way — a filtered cut of the archive, serialised into formats other systems already read.

An agent can extend the graph as readily as read it. Its analysis runs on a branch of its own: it adds claims, cites the records it read, and leaves the sources untouched. Whoever reviews it later can see every record the analysis drew on.

Similar technologies

Twenty systems keep history in ways that overlap with this one, and several of them are further along at the job described above. The neighbours page takes each in turn: what it is for, where it goes further than Ranke, where Ranke goes further, how the two would compose, and the terms it comes on.

git TerminusDB Neo4j Datomic XTDB Fluree Zep Utopia Chainloop Archivista GUAC Velociraptor Timesketch DFIR-IRIS Archivematica IPFS Sigstore C2PA SCITT Nanopublications

What it aligns with

W3C PROV-DM The standard vocabulary for provenance: entities, activities, agents. A Ranke-Graph maps onto it, and holds the provenance in the same graph as the content.
CASE and UCO How a cyber investigation is described: chain of custody, meaning who handled the data, when and where, and chain of evidence, meaning which tools treated it. The same discipline, written for investigators.
EDTF The Library of Congress's format for a date known only approximately, which is what the presumed date of origin needs.
